ICE2A765P2

Off-Line, SMPS Current Mode Controller, integrated 650V/800V CoolMOS, DIP-8, Input Undervoltage Lockout

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.90~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.90~2.00

PartNumber:: ICE2A765P2

Brand:: Infineon Technologies AG - Infineon | Pack: TO | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Yinky's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-19

From Other Seller

Part Number:ICE2A765P2
US $1.90 - 2.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The second generation ICE2A765P2 provides several special enhancements to satisfy the needs for low power standby and protection features. In standby mode frequency reduction is used to lower the power consumption and support a stable output voltage in this mode. The ICE2A765P2 frequency reduction is limited to 21.5 kHz to avoid audible noise. In case of failure modes like open loop, overvoltage or overload due to short circuit the device switches in Auto Restart Mode which is controlled by the internal protection unit. By means of the internal precise peak current limitation the dimension of the transformer and the secondary diode can be lower which leads to more cost efficiency.

Parametrics

ICE2A765P2 absolute maximum ratings: (1)Drain Source Voltage ICE2A165/265/365 VDS: 650 V Tj=110℃; (2)Drain Source Voltage ICE2A180/280 VDS: 800 V; (3)VCC Supply Voltage VCC: -0.3 to 22 V; (4)FB Voltage VFB: -0.3 to 6.5 V; (5)SoftS Voltage VSoftS: -0.3 to 6.5 V; (6)ISense ISense: -0.3 to 3 V; (7)Junction Temperature Tj: -40 to 150 ℃; (8)Storage Temperature TS: -50 to 150 ℃; (9)Thermal Resistance Junction-Ambient, RthJA: 90 K/W.

Features

ICE2A765P2 features: (1)650V/800V avalanche rugged CoolMOS Only few external components required; (2)Input Vcc Undervoltage Lockout; (3)67kHz/100kHz switching frequency; (4)Max duty cycle 72%; (5)Low Power Standby Mode to meet European Commission Requirements; (6)Thermal Shut Down with Auto Restart; (7)Overload and Open Loop Protection; (8)Overvoltage Protection during Auto Restart; (9)Adjustable Peak Current Limitation via external resistor; (10)Overall tolerance of Current Limiting < %; (11)Internal Leading Edge Blanking; (12)User defined Soft Start; (13)Soft driving for low EMI.
